The SMB Female Straight Connector for RG316 Cable is a compact, high‑frequency RF connector designed for applications where space is tight but performance still matters. Engineered to mate with standard SMB male plugs, it uses a convenient push‑on interface that allows quick connect and disconnect without tools, making it an excellent choice for test benches, lab setups, and field service work. Optimized for RG316 coaxial cable, this connector maintains a characteristic impedance of 50 ohms, supporting stable signal transmission in typical RF and microwave ranges used in communication, instrumentation, GPS, and antenna systems. When correctly crimped, it provides a secure mechanical bond and consistent electrical contact, helping to minimize insertion loss and reflections across the operating band. The straight body style makes routing more predictable and easier to manage in tight enclosures, rack units, or densely packed PCBs and modules. A robust metal shell offers good mechanical strength and supports effective shielding, helping to reduce interference and preserve signal integrity. The internal contact geometry is designed to deliver reliable mating cycles, so the connector can be connected and disconnected multiple times without compromising performance. This connector is well suited for custom RF jumpers, interconnects between RF boards and front‑panel connectors, antenna leads, and retrofits where RG316 cable is already in use. With its combination of a compact SMB form factor, quick push‑on coupling, and compatibility with RG316, it offers an efficient and professional solution for engineers, technicians, and hobbyists working on modern RF projects. Used with the proper crimp tools and technique, the SMB Female Straight Connector for RG316 Cable delivers a neat, repeatable termination that helps keep your RF systems consistent, serviceable, and easy to expand over time.

• Designed specifically for RG316 coaxial cable with 50-ohm impedance
• SMB female straight interface compatible with standard SMB male plugs
• Push-on coupling for quick
• tool-free connection and disconnection
• Compact form factor suitable for dense
• space-constrained RF layouts
• Crimp-style termination for secure mechanical and electrical contact
• Metal body construction for durability and effective RF shielding
• Suitable for RF modules
• antennas
• test equipment
• and communication systems
• Supports low-loss transmission across typical RF and microwave frequency ranges
